Technical Specifications
| Input Data(DC) | Output Data(AC) | Protection Function |
| Recommended solar panel input power: 275-530W*2 | Max. Continuous output power: 800W | Type of enclosure: IP67 |
| Number of DC input connections: MC4*2 | Nominal output voltoge: 230V | Protective class: Class 1 |
| Max. Input voltage: 60V | Output voltage range: 280W-550W | Operating ambient temp.: -40°C to +65°C |
| PV operating voltage: 25-55V | Max. Continuous output current: 3.47A | Indication light quantity: Working status: Led light+WiFi Signal Led light |
| Start-up voltage: 20V | Nominal output frequency: 50Hz | Communication connection mode: WI-Fi/2.4G |
| MPPT tracking range: 18-55V | Output frequency range: 45 - 55Hz | Cooling method: Natural cooling(no fan) |
| MPPT tracking accuracy: >99.5% | Maximum number of branch circuit connections: 230VAC: 5sets | Working environment: Indoor and Outdoor |
| Max. Continuous input current: 13.5A*2 | Peak efficiency: 96% | Weight：2.8KG, Size (L*W*H): 260mm*225mm*32mm |
